Fresco™ Wall & Ceiling Products

Overview

Fresco™ Wall & Ceiling Products feature a specially formulated face coating that provides the look of painted gypsum or plaster along with high performance sound absorption. Fresco™ is highly customizable as wall & ceiling panels, baffles or ceiling clouds in various shapes and sizes. Fresco™ comes in either standard white or is available with custom color match to any color with Sherwin Williams to achieve the perfect color palette and design.

Applications

Fresco™ Wall & Ceiling Products are the ideal customized wall & ceiling treatment for areas that require sound & noise control. Some applications include Schools/Classrooms, Churches, Auditoriums, Conference Areas, Lobbies, Restaurants, and Meeting Rooms.

Technical Features

Core: 6-7 PCF Fiberglass
Core Facing: ⅛” 16-20 PCF High Density Fiberglass
Thickness:⅞”, 1⅛”, 1⅝”, 2⅛”
Sizes: Any Size Up to 48″ x 120″
Special Sizes & Shapes: Available Upon Request
Edge Profile: Square, Bevel, Radius, Miter, Others Available Upon Request
Finish: Decorative Coated Finish Resembling Painted Gypsum or Plaster
Facing: Standard White or Custom Color Match with Sherwin Williams
Fasteners: Z-Clip, Z-Bar, Eyelets, D-Ring, Cloud Anchor
- (See AcousTech™ Ceiling Clouds for Horizontal Ceiling Suspension Application & AcousTech™ Ceiling Baffles for Vertical Ceiling Suspension Application)
Dimensional Tolerance: +/- 1/16″ (.0625″)
Fire Performance: Class 1/A, UL 723 / ASTM E84

Key Features

Highly Customizable as Wall & Ceiling Panels, Baffles and Ceiling Clouds
Design Flexibility with Standard and Custom Sizes & Shapes Available
Decorative Coated Finish Resembling Painted Gypsum or Plaster
Custom Color Match to Any Color with Sherwin Williams
Excellent Light Reflectance of 90% for Standard White
Dual-Density Core Engineered for Exceptional Low Frequency Absorption with Benefit of High Impact Resistance
Highest Sound Absorption Efficiency & Performance
Easy to Install with Fully-Concealed Mounting Hardware Included
LEED Credit Eligibility With Installation of These Products
Indoor Air Quality (IAQ) & Low VOC Meets GREENGUARD Children & Schools Certification and California Title 24

Acoustical Data

Frequency (Hz)	125	250	500	1K	2K	4K	NRC
Fresco 1.1 - 1-1/8" Panel	0.10	0.48	1.00	1.16	1.07	0.99	0.95
Fresco 1.6 - 1-5/8" Panel	0.25	0.85	1.15	1.11	1.05	1.01	1.05
Fresco 2.1 - 2-1/8" Panel	0.38	0.97	1.17	1.12	1.06	0.95	1.10

Finishes

Standard White

Color Match with Sherwin Williams
