Overview
Prime7-Fe™ is an attractive, furniture- grade hardwood wall system easily installed to most any architectural surface. Its decorative finishes and profiled design combine to provide single-dimension mid-high frequency diffusion for control of flutter echo, while preserving the natural ambiance of the space. Type – LFA (optional) has rear reliefs engineered to provide additional absorption below the frequency range of the diffuser cut-off frequency. Additionally, Prime7-Fe™ profiles can be installed with a rear air space and with slight separations, along with a glass or polyester fiber back-layer for increased low frequency absorption. This product is a quadratic residue design derived from mathematical number theory sequences for reflection phase grate principles, then precisely manufactured to provide a combination of mid-high frequency diffusion with low frequency absorption; all in one product. Finished profiles are solid core materials to prevent resonances and resist damage. Finishes are factory applied on standard or customer specified wood species.
applications
Prime7-Fe™ is ideal for rooms and spaces where flutter echo is a consideration. Some applications include:
- Performing Arts Centers
- Lecture Halls
- Music Spaces
- Recording Studios
- Core: Manufactured Hardwood Plank
- Thickness (Nominal): 1″ (102 mm)
- Sizes (Nominal): 4″ x 96″ for Most Wood Species
- Standard Hardwood Options: Maple, Cherry, Oak, Poplar
- Finish: Natural, Stain, Lacquer, Paint, Custom
- Installation Methods: Nail, Screw, Adhesive, As Required
- FSC Certifications: FSC Mix, FSC 100%
- Fire Performance: Class A
- Provides Single-Dimension Mid-High Frequency Diffusion for Control of Flutter Echo Without Deadening the Room
- Furniture-Grade Wood Acoustical Moldings for Ceiling & Walls
- Factory Applied Finishes to Standard or Customer-Specified Wood Species
- Custom Stain Options Available to Coordinate with Designerâs Color Palette
- Helmholtz Mounting Option for Added Low-Frequency Absorption
- Type-LFA (Optional) has Rear Reliefs Engineered to Provide Additional Absorption Below the Frequency Range of the Diffuser Cut-Off Frequency
- Solid Core Materials to Prevent Resonances & Resist Damage
- FSC Certified Materials Available
- Up to 10 LEED Credits May Apply With Installation of These Products
Acoustical Data
Acoustical Performance—Absorption Coefficients
| Frequency (Hz) | 125 | 250 | 500 | 1K | 2K | 4K | 8K |
|---|---|---|---|---|---|---|---|
|
Absorption Coefficients, Type A Mount |
0.04 |
0.05 |
0.06 |
0.08 |
0.09 |
0.04 |
0.05 |
Acoustical Performance—diffusion Coefficients
| Frequency (Hz) | 1K | 2K | 4K | 8K | 12.5K | 16K | mean |
|---|---|---|---|---|---|---|---|
|
Diffusion Coefficients, AES=4id-2001 |
0.63 |
0.67 |
0.78 |
0.74 |
0.73 |
0.74 |
0.72 |
Acoustical Performance—Type LFA - Absoprtion Coefficients
| Frequency (Hz) | 125 | 250 | 500 | 1K | 2K | 4K | NRC |
|---|---|---|---|---|---|---|---|
|
Absorption Coefficients (AcousTech™ 1" Fiberglass Core Back-Mounted) |
0.12 |
0.39 |
1.09 |
0.66 |
0.41 |
0.51 |
0.65 |
