Overview
ToneWood™ Micro-Perforated natural wood-faced panel systems provide the attractive look of natural wood in addition to our high-performance acoustical technologies for effective control of sound. ToneWood™ Micro-Perforated panels and planks are constructed with fire rated cores that are layered with micro-perforated wood veneers. Designed to provide the aesthetics of a solid wood panel, the micro-perforations disappear at a distance. Exceptional looks, features and performance insure interior spaces sound and feel comfortable for occupants to enjoy without feeling fatigue or strain during their time using the space.
applications
ToneWood™ Micro-Perforated is the ideal decorative wall & ceiling treatment for rooms and spaces where sound and noise control are a consideration. Some applications include:
- Lecture Halls
- Auditoriums
- Performing Arts Centers
- Churches
- Recording Spaces
- Music Rooms
- Office Buildings
- Courtrooms
- Core: Fire Rated FRP or Fire Rated MDF
- Thickness: ¾”
- Panel Sizes: Any Size Up to 48″ x 120″
- Standard Plank Size: 5″ x 96″
- Special Sizes & Shapes: Available Upon Request
- Standard Micro-Perf Options: .55MM & 1MM
- Edge Profile: Flush or Reveal, Plain or Wood Finish
- Facing: Wood Veneer, Laminates and Custom Finish Facings
- Finish: Natural, Stain, Lacquer, Paint, Custom
- Fasteners: Z-Clip, Z-Bar, Ceiling Lay-In
- FSC Certifications: FSC Mix, FSC 100%
- Sound Absorption: Optional AcousTech™ or TheaterBlack™ Backing
- Fire Performance: Class 1/A, UL 723 / ASTM E84
- Wood Veneer, Laminates and Custom Finish Facings
- Facing is Micro-Perforated from a Range of Design Styles & Pattern Options with Custom Patterns Available
- Micro-Perforation Size, Configuration & Selection of Straight or Compound
- Optional Black Acoustical Fleece Backing
- FSC Certified Materials Available
- Additional Absorption of Low Frequency Sound Energy May be Obtained with Simple, Alternate Mounting Methods
- Custom-Printed Digital Imaging Available
- Easy to Install with Fully-Concealed Mounting Hardware Included
- Up to 10 LEED Credits May Apply With Installation of These Products
Acoustical Data
| Frequency (Hz) | 125 | 250 | 500 | 1K | 2K | 4K | NRC |
|---|---|---|---|---|---|---|---|
|
Type A Mounting (+1" TheaterBlack™ Glass Fiber Backing) |
|||||||
|
ToneWood™ 7 Micro-Perf |
0.28 |
0.89 |
0.90 |
0.89 |
0.87 |
0.69 |
0.90 |
|
Type E400 Mounting (+2" TheaterBlack™ Glass Fiber Backing) |
|||||||
|
ToneWood™ Micro-Perf |
0.39 |
0.95 |
0.91 |
0.92 |
0.88 |
0.74 |
0.90 |
|
ToneWood™ Micro .55MM - Wall Mount |
0.40 |
||||||
|
ToneWood™ Micro .55MM - Type A Mounting + 1" TheaterBlack Glass Fiber Backing |
0.85 |
||||||
|
ToneWood™ Micro .55MM - Type A Mounting + 2" TheaterBlack Glass Fiber Backing |
0.85 |
||||||
|
ToneWood™ Micro 1MM - Wall Mount |
0.50 |
||||||
|
ToneWood™ Micro 1MM - Type A Mounting + 1" TheaterBlack Glass Fiber Backing |
0.90 |
||||||
|
ToneWood™ Micro 1MM - Type A Mounting + 2" TheaterBlack Glass Fiber Backing |
0.95 |
||||||
Finishes
- ToneWood™ Micro-Perforated Data Sheet
- ToneWood™ Micro-Perforated Patterns
- ToneWood™ Micro-Perforated Installation Detail
- ToneWood™ Panel Installation Detail
- ToneWood™ Plank Wall Installation Detail
- ToneWood™ Plank Ceiling Installation Detail
- Handling of ToneWood™
- Maintenance & Cleaning for AVL Wood Products
- Finishes Guide
- Warranty – 1 Year – Sample
