Prime7™ Natural Quadratic Residue Diffuser

Overview

Prime7™ Natural is a computer-optimized 1-D diffuser design utilizing quadratic residue diffuser number theory and periodic reflection phase grate principles in a highly finished acoustical product that can be mounted to most architectural surfaces. Its solid wood construction is an attractive complement to architectural design and brings a warm appearance to any space. These products are precisely engineered and manufactured to provide one-dimensional broadband diffusion and wide-range scattering of acoustical sound energy without resonance, high-Q reflections, or unwanted absorption. Prime7™ Natural are meticulously constructed to dampen unwanted resonances and resist impact and damage.

applications

Prime7™ Natural is ideal for rooms and spaces that require diffusion to help scatter and blend the sounds in a room for the listening enjoyment of both music and speech. Some applications include:

  • Auditoriums
  • Performing Arts Centers
  • Lecture Halls
  • Convention Centers
  • Churches
  • Music Spaces
  • Recording Studios

  • Thickness (Nominal): 9″
  • Sizes (Nominal): 2’x2′, 2’x4′, 4’x4′
  • Facing: Wood Veneer, Laminates and Custom Finish Facings
  • Finish: Natural, Stain, Lacquer, Paint, Custom
  • Installation Methods: Cleat Mount for Wall Installations
  • Weight:  6.2 Lbs/ Square Foot
  • FSC Certifications: FSC Mix, FSC 100%
  • Fire Performance: Class A

  • Quadratic Residue Prime7™ Periodic Reflection Phase Grate Diffuser
  • One-Dimensional Diffusion with Wide-Range Scattering
  • Two-Dimensional Diffusion & Sound Scattering Can Be Achieved by Grouping Installed Products in an Altering Pattern Array
  • Sequence Same for All Diffuser Sizes
  • Wood Veneer, Laminates and Custom Finish Facings
  • Custom Veneers Available to Coordinate with Designer’s Color Palette
  • FSC Certified Materials Available
  • Prime7™ Ceiling Diffuser’s Precise Tolerances & Mono-Block Construction Insures No Resonances, Rattles or Sympathetic Vibration Will Be Caused or Heard, and High STC Ratings are Achieved
  • Up to 10 LEED Credits May Apply With Installation of These Products

Acoustical Data

Acoustical Performance - Absorption Coefficients

Frequency (Hz) 125 250 500 1K 2K 4K NRC
Absorption Coefficients Type A Mounting
0.20
0.22
0.38
0.25
0.21
0.19
0.25

Acoustical Performance - Sound diffusion & Scattering

Frequency (Hz) 125 250 500 1K 2K 4K 8K
Diffusion Coefficients
0.19
0.21
0.44
0.46
0.48
0.43
0.35
Scattering Coefficients
0.04
0.24
0.85
0.66
0.86
0.90
0.93

Finishes

Other Wood Species and Slicing Options Available.
